If you want to build high-quality concrete floors, you need the right equipment. Traditional concrete leveling takes a lot of time and labor. Today, more and more construction teams choose modern machines to do the work. Our professional concrete laser screed for sale helps you get perfectly flat floors quickly. This machine uses advanced laser technology to control the leveling height automatically. It makes the concrete surface very smooth and saves you a lot of energy.
Whether you work on factory floors, large warehouses, or parking lots, our equipment can meet your needs. YG is a trusted manufacturer of industrial machinery. We offer high-quality products at competitive factory prices to help your business grow.
Get A Free Quote From YG Factory
Why You Need A Concrete Laser Leveling Machine
A concrete laser leveling machine is a great investment for any construction company. It changes the way people lay concrete floors. Here are the main benefits of using this machine on your job site:
- Higher Precision: The machine uses a laser transmitter and receiver. It guides the leveling head to keep the floor perfectly flat. The error is very small, which manual work cannot match.
- Faster Work Speed: It can cover a large area in a very short time. Your project can finish much earlier than planned.
- Less Labor Cost: You do not need a big team to level the concrete. One or two workers can operate the machine easily.
- Better Concrete Strength: The strong vibration system removes air pockets from the concrete. This makes the floor dense, strong, and durable.
Key Features Of Our Laser Concrete Leveling Machine
When you buy a laser concrete leveling machine from YG, you get excellent technology. We design our machines carefully to ensure they work well in tough environments.
- Strong Engine Power: We use high-quality engines and generator sets. For example, our machines feature the famous GX390 electric start engine, which provides 13 horsepower. It gives stable power for long working hours.
- Smart Laser System: The microcomputer laser scan system automatically adjusts the leveling head. It reads the laser signal 10 times per second to keep accuracy.
- Easy Handling: All our models are walk-behind types. They use handle controls or handgrip controls with stepless speed-walking. You can move the machine forward and reverse smoothly.
- Self-Leveling Screed Head: The screed head combines vibrating, leveling, and screeding together. It automatically maintains balance during work.
Inquire Product Details & Prices Now
Choose The Right Concrete Laser Screed Machine
Every construction project is different. That is why we offer different models of the concrete laser screed machine. Below is a detailed specification table of our hot-selling models. You can compare them and choose the best one for your business.
Technical Data Table
| Model | YGJX31 | YGJX32 | YGJX33 | YGJX34 |
| Engine Model | Generator set | GX390 Electric start | GX390 Electric start | GX390 Electric start |
| Power | 2.0 kW | 13 hp / 3600 rpm | 13 hp / 3600 rpm | 13 hp / 3600 rpm |
| Fuel Tank (L) | 14.5 | 6.5 | 6.5 | 6.5 |
| Drive Type | Motor | Hydraulic motor | Hydraulic motor | Hydraulic motor |
| Running Mode | Infinitely variable speed | Handle control, stepless speed | Handle control, stepless speed | Handle control, stepless speed |
| Running Speed | 0-36 m/min | 0-45 m/min | 0-65 m/min | 0-45 m/min |
| Suggest Work Speed | 5 m/min | 5 m/min | 5 m/min | 5 m/min |
| Screed Head Type | Self-leveling | Electric control, self-leveling | Self-leveling | Hydraulic control, self-leveling |
| Screed Width | 2500 mm | 2500 mm | 2500 mm | 2500 mm |
| Exciting Force | 500 N | 500 N | 500 N | 500 N |
| Vibration Frequency | 50 Hz | 50 Hz | 50 Hz | 50 Hz |
| Laser Control Type | Microcomputer laser scan | Microcomputer laser scan | Microcomputer laser scan | Microcomputer control |
| Operation Mode | Walk-behind | Walk-behind | Walk-behind | Walk-behind |
| Forward / Reverse | Handgrip control, stepless | Hydraulic control | Handgrip control, stepless | Hydraulic control |
| Working Size (mm) | 2758*2622*1980 | 2740*2659*1980 | 2578*2643*1980 | 2780*2622*1980 |
| Weight (kg) | 295 | 365 | 380 | 410 |
As you can see from the data, all four models have a standard screed width of 2500 mm. They also share a strong 500 N exciting force and 50 Hz vibration frequency. If you want a lightweight model with a large fuel tank, YGJX31 is a good choice. If you prefer hydraulic driving and heavier weights for tough jobs, you can choose YGJX32, YGJX33, or YGJX34.
Contact Our Experts To Choose Model
Important Tips For Operating A Concrete Laser Screed
Using a concrete laser screed machine is simple, but workers must follow correct steps to get the best results. Good operation ensures the floor looks perfect and the machine lasts a long time.
- Set Up The Laser Transmitter Correctly: Place the laser transmitter on a stable tripod. Make sure there are no obstacles between the transmitter and the machine receiver.
- Check The Concrete Slump: The concrete mix should not be too wet or too dry. A suitable slump helps the vibrating screed head level the surface evenly.
- Maintain Steady Speed: Walk with the machine at the suggested working speed of 5 meters per minute. Do not rush, and do not stop in one place for too long.
- Clean Immediately After Use: Concrete hardens quickly. Wash the screed head and the wheels with clean water right after you finish the job.
How To Buy Best Concrete Laser Screed For Sale From YG
YG is a leading industrial machinery manufacturer in China. We export equipment to many countries worldwide. If you are searching for a reliable concrete laser screed for sale, we are ready to serve you.
Our team provides complete support, from choosing the machine model to safe shipping and after-sales service. We test every machine before it leaves our factory to guarantee its quality. Tell us your project size and requirements, and we will offer you the most suitable solution.
