Are you tired of slow foundation work? A high-quality pile head breaking machine is the best tool to speed up your construction projects. Whether you work in the USA, Europe, Saudi Arabia, or Singapore, you need a fast and clean way to cut concrete piles. YG modular design allows you to adjust the equipment to fit any pile size from 400mm up to 2500mm. With a powerful maximum thrust of 300KN, this machine delivers high performance without damaging the inner rebar.
Hydraulic Pile Breaker Specifications
YG builds our machines with top-grade materials to match your heavy excavators and pump stations. You can change the number of modules to handle different pile diameters on site.
Check the official factory technical data below to find the perfect match for your carrier fleet:
| Module Number | PCS | 4 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 | 16 | 17 | 18 |
| Combination of the total weight | KG | 1600 | 2640 | 2970 | 3300 | 3630 | 3960 | 4290 | 4620 | 4950 | 5280 | 5610 | 5940 |
| Pile diameter range | mm | 400-600 | 600-800 | 800-1000 | 1000-1150 | 1150-1300 | 1300-1500 | 1500-1650 | 1650-1800 | 1800-1970 | 1970-2200 | 2200-2360 | 2360-2500 |
| Hydraulic excavator | T | 20T-30T | 30T-40T | Hydraulic system/pump station | |||||||||
| Max.Thrust | 300KN | Max.Cylinder required | 20L/min | Machinery Tonnage | ≥20T | Location pinΦ35 | |||||||
| Max.Cylinder Trip | 300mm | Chisel diameter | 110mm | Singlemodule weight | 335KG | ||||||||
| Max.Cylinder Pressure | 300MPa | Max.Hoist Capacity | ≤500mm | Singlemodulesize | 1015*865*340mm | ||||||||
Our system uses a strong location pinΦ35 to keep every single module firmly locked together during heavy operations.
Contact YG Engineers for Product Selection
Why Should You Choose A Hydraulic Pile Breaker For Your Project?
Traditional hand tools take too much time and labor. A modern hydraulic pile breaker solves this problem by using fluid power to crush concrete in seconds.
Here is why this tool changes your job site completely:
- It saves labor costs because one operator can do the work of ten people.
- It operates with low noise and low vibration, which keeps your job site safe and quiet.
- It leaves the steel rebar completely clean and undamaged for the next construction step.
- It connects easily to your existing machinery fleet.
Get a Free Product Catalog Now
How Does The Concrete Pile Cutter Handle Different Pile Sizes?
Every job site has different needs. Our concrete pile cutter features a highly smart modular design. This means your crew can add or remove links like a chain to change the working diameter.
The process is quick and simple:
- Your team adds more modules for large bridge foundation piles up to 2500mm.
- Your team removes modules for smaller building foundation piles down to 400mm.
- The system connects directly to a hydraulic excavator or a portable pump station.
- A minimum flow rate of 20L/min ensures smooth and continuous cylinder movement.
How To Maintain Your Pile Breaking Machine for Long Life?
If you want your machinery to last for many years, you must take care of it daily. Proper maintenance saves your team from sudden breakdowns during critical working hours.
Follow these simple steps every day:
- Inject high-quality grease into the moving joints before every shift.
- Check the location pinΦ35 regularly to ensure it stays tight and secure.
- Look for any oil leaks around the hydraulic cylinder tubes and hoses.
- Keep the concrete dust away from the main seals after finishing the job.
Ask for a Technical Maintenance Manual
Why Is This Concrete Pile Cutting Machine Ideal For Urban Sites?
City projects in places like Singapore or European capitals have very strict rules about noise and safety. A traditional large drop hammer creates massive sound waves and dust clouds.
YG concrete pile cutting machine works through pure hydraulic pressure instead of hard impacts:
- It crushes the concrete inward quietly without throwing dangerous stone chips into the air.
- It protects nearby historic buildings from ground vibration damage.
- It operates perfectly in tight spaces where large cranes cannot fit.
- It requires only a standard machinery tonnage of ≥20T to begin working safely.
Case: Singapore Site Speeds Up Foundation Work Using YG Modular Concrete Pile Cutting Machine
A leading foundation contractor in Singapore faced a strict noise limit of 75 decibels near a residential zone. They needed to remove over 500 cast-in-place concrete piles quickly without disturbing the local residents. The team replaced their traditional jackhammers with our advanced concrete pile cutting machine.
By connecting a 12-module setup to their 30-ton excavator, they crushed the 1400mm diameter pile heads quietly and smoothly. The project manager reported zero flying debris and zero vibration complaints from the neighborhood. Most importantly, the crew finished the entire foundation phase two weeks ahead of schedule, keeping the project completely safe and on track.
Get a Quick Response from YG Team!
How Do You Install A Concrete Pile Breaker On Your Excavator?
Hooking up the attachment to your carrier fleet does not require advanced engineering skills. Our design allows your team to finish the installation in less than an hour.
Here is how you connect the system:
- Hang the attachment onto the excavator bucket arm or a lifting crane hook.
- Connect the oil inlet and outlet hoses to the auxiliary hydraulic lines of the excavator.
- Ensure your hydraulic system provides the required 20L/min flow and can withstand the 300KN backpressure.
- Test the controls from the cabin to see if all cylinders move inward at the exact same time.
