Managing electronic scrap is a huge challenge for modern recycling factories. Circuit boards, hard drives, and old computers take up too much space and are hard to separate. A professional e waste shredder is the ultimate machine to solve this problem. YG heavy-duty equipment uses high-strength alloy steel blades to cut down large electronics into small, uniform pieces. This size reduction is the critical first step for automated sorting lines. By crushing the materials efficiently, you can easily separate valuable metals like copper and gold from plastics.
Whether you run a small local scrap yard or a large-scale industrial recycling center, this machine improves your workflow. It reduces manual labor costs and protects your workers from sharp components. YG designs every unit with reinforced structures to handle continuous, 24-hour operations without unexpected breakdowns.
How Does an E Waste Shredder Work?
The working principle is straightforward. An e waste shredder uses rotating cutters to tear and shear materials. The machine pulls in electronic items through a hopper. Inside the cutting chamber, blades grab and cut the material into smaller pieces.
Most shredders operate at low speed but with high torque. This design gives them the power to break tough materials like metal casings and circuit boards. Low speed also means less heat and dust.
Here is what happens during the shredding process:
- Feeding: Items enter through a hopper
- Cutting: Rotating blades shear and tear the material
- Sizing: Screens control the final particle size
- Discharge: Shredded pieces exit for downstream separation
Some models include advanced features like automatic reverse. This prevents jams when the machine hits tough materials. PLC controls monitor load and adjust operation in real time.
Types of E Waste Shredders
Not all shredders are the same. You need to choose based on your material and output requirements. Here are the main types:
Single-Shaft Shredders
One rotating shaft works against a fixed counter knife. This design produces consistent particle sizes. It works well for plastics and circuit boards.
Dual-Shaft Shredders
Two shafts rotate in opposite directions. They provide high torque for tough materials. This type is common for hard drives, servers, and appliances .
Four-Shaft Shredders
Two cutting shafts plus two feeding shafts. An integrated screen ensures uniform output. This design gives the finest particle sizes . It is ideal for PCB recycling and high-security data destruction.
YG Series E Waste Shredder Specifications
Our YG series covers a full range of capacities. Choose the model that fits your processing volume
| Model | YG-600 | YG-800 | YG-1000 | YG-1200 | YG-1400 | YG-1600 | YG-1900 | YG-2200 | YG-2600 |
| Power | 4-15*2 kw | 4-22*2kw | 4-30*2kw | 4-37*2kw | 4-45*2kw | 4-75*2KW | 4-90*2kw | 4-132*2kw | 4-160*2kw |
| Spindle Model | 18-20r/min | 18-35r/min | 18-35r/min | 18-35r/min | 14-35r/min | 14-25r/min | 14-25r/min | 16-25r/min | 16-25r/min |
| Capacity | 2-3t/h | 3-5t/h | 5-8t/h | 6-10t/h | 8-12t/h | 12-18t/h | 16-22t/h | 20-26t/h | 25-60t/h |
| Broken Size | 3-10cm | 3-10cm | 3-10cm | 3-10cm | 3-10cm | 3-10cm | 3-10cm | 3-10cm | 3-10cm |
| Hopper Size | 820*900mm | 900*1000mm | 1200*1000mm | 1400*1000mm | 2000*2000mm | 2300*2000mm | 2300*2000mm | 2500*1800mm | 2425*1400mm |
| Dimensions | 2600*2000*1900mm | 2800*2000*1900mm | 3000*2000*1900mm | 3200*2000*1900mm | 4000*1700*2400mm | 5000*3000*2400mm | 6000*3500*2400mm | 7000*4000*4500mm | 8200*4000*4300mm |
Get a Quote for Your Shredder Model
E Waste Shredder vs. Traditional Processing Methods
Many facilities still use manual disassembly or whole-item crushing to handle e-waste. But these old methods have serious problems. An e waste shredder offers clear advantages. Here is a direct comparison:
Manual Disassembly
Workers take apart electronics by hand to remove parts. This is slow, dangerous, and expensive. Labor costs are high. Workers risk injury from glass, sharp metals, and toxic dust. The process cannot handle large volumes. It is not practical for modern recycling operations.
Whole-Item Crushing
Some operations use hammer mills or crushers that smash entire items. These machines do not separate materials. They mix everything together. This makes it very hard to recover valuable metals. Dust and fire risks are high because the impact creates heat and sparks.
Landfill Disposal
The worst option. Electronics go straight to the dump. Valuable materials are lost forever. Toxic substances like lead and mercury leak into soil and water. This damages ecosystems and human health.
How an E Waste Shredder Improves the Process
- Better material recovery: Controlled shearing liberates metals, plastics, and glass. These can then be sorted into pure streams. Recovery rates for copper and gold are much higher.
- Safety: Low-speed cutting with safety interlocks protects workers. Integrated dust collection keeps hazardous particles contained. Fire suppression reduces burning risks.
- Compliance: Shredding meets data destruction standards like DIN 66399. Manual methods cannot guarantee that data is truly gone.
- Volume reduction: A shredder can reduce e-waste volume by 80%. This saves space in storage and transport.
Simply put, an e waste shredder is faster, safer, and more profitable than traditional methods. It turns a waste problem into a resource opportunity.
Talk to an Expert About Your Application
Key Applications for E-Scrap Shredder Machines
An e scrap shredder serves many industries. Here are the most common applications:
IT Asset Disposition (ITAD)
Companies that retire old computers, servers, and storage devices use e scrap shredders. Physical destruction ensures data cannot be recovered. This meets compliance requirements like GDPR and HIPAA.
PCB Recycling
Printed circuit boards contain valuable metals like gold, copper, and palladium. Shredding liberates these metals for downstream recovery. Four-shaft models produce particles under 30mm, which is optimal for separation equipment .
E-Waste Recycling Facilities
These plants process mixed electronics from collection programs. They use e waste recycling equipment to break down items before sorting. The shredder is the first step in the recovery process.
Manufacturing Scrap
Electronics manufacturers generate scrap from production. They use shredders to recycle defective parts and off-cuts.
Security and Data Destruction Standards
Data security is a major reason to use an e waste shredder. Hard drives and SSDs contain sensitive information. Software erasure is not always enough. Physical shredding guarantees destruction.
DIN 66399 is the international standard for data destruction. It defines security levels and required particle sizes :
| HDD (Magnetic) | H-4 | 2,000 mm² |
| SSD (Chip-based) | E-3 | 160 mm² |
| Optical (CD/DVD) | O-2 | 800 mm² |
For SSD destruction, a four-shaft e waste shredder is often required. A standard dual-shaft may not reduce chips enough to meet the standard.
Safety Features for Electronic Waste Crusher Equipment
Electronic waste can be dangerous. Batteries may catch fire. Dust can contain lead and other toxins. A modern electronic waste crusher includes safety systems to address these risks.
Here are critical safety features to look for:
- Fire suppression: Infrared detectors trigger water mist or foam
- Inert gas injection: Nitrogen floods the cutting chamber to prevent combustion
- Low RPM operation: Operating below 20 RPM reduces friction heat
- Temperature monitoring: Thermographic cameras detect heat spikes
- Dust extraction: HEPA filtration removes hazardous particles
Dust management is especially important. E-waste contains brominated flame retardants and heavy metals. A sealed electronic waste crusher with negative pressure keeps these contaminants contained.
How to Choose the Right E Waste Recycling Equipment
Selecting e waste recycling equipment requires careful planning. Here is a practical checklist:
1. Define Your Throughput
How much material do you process per hour? Capacities range from 2/h to 60 t/h . Choose a machine that matches your volume.
2. Identify Your Material
What items will you shred? Hard drives need different cutters than appliances. Mixed e-waste requires versatile shredders.
3. Determine Output Size
What particle size do you need? Smaller sizes improve separation but reduce throughput. Match size to your downstream equipment.
4. Check Compliance Requirements
Do you need to meet data destruction standards? Do local regulations require specific safety features?
5. Evaluate Power and Space
Shredders require significant power (75-320 kW) and floor space. Ensure your facility can support the machine.
Request a Custom Selection Guide
Environmental Benefits of Using an E Waste Shredder
Proper e-waste processing protects the environment. Here is how an e waste shredder helps:
- Reduces landfill waste: Shredding reduces volume by up to 80%
- Recovers valuable materials: Metals and plastics go back into production
- Prevents toxin release: Controlled processing contains hazardous substances
- Supports circular economy: Recycled materials reduce the need for virgin resources
The WEEE Directive in Europe and R2v3 certification in the US set standards for responsible recycling . Using certified e waste recycling equipment helps you meet these requirements.
Frequently Asked Questions
Technically yes, but it is high risk. Best practice is to remove batteries first. If removal is not possible, use a shredder with fire suppression and inert gas injection .
With a four-shaft shredder producing particles under 30mm, followed by eddy current separation, copper recovery can exceed 95% . Results depend on particle size and separator tuning.
Shredding liberates the metal. You then need electrostatic or optical sorters downstream. These separate gold-bearing PCB fragments from plastic .
Still Have Questions? Ask YG Engineers
Why Partner with YG Manufacturer Manufacturer
Choosing the right manufacturer matters. Look for these qualities:
- Experience: Proven track record in e-waste processing
- Customization: Ability to tailor machines to your needs
- Support: Spare parts availability and technical assistance
- Scale: Factory area over 40,000 m² and engineering teams of 800+
Ready to improve your e-waste processing? YG e waste shredder experts can help you find the right solution. Contact us for a consultation.
Need a custom quote? Send us your material specs and throughput requirements.
