A portable concrete pump for sale is a compact, self-contained machine designed to move liquid concrete through pipes using hydraulic pressure. It is typically used on small to medium construction sites, including residential buildings, road repairs, and farm construction. YG manufactures these pumps with features like a powerful motor, wear-resistant S-valve, and remote control operation. If you are looking for a reliable machine to speed up your concrete placement, contact YG for more product details.
YG Portable Concrete Pump for Sale Specifications -OEM Support
Before you compare a portable concrete pump for sale, you should understand its main technical parameters. Here are the typical specifications for a standard electric model from YG.
Small Concrete Pump Specifications
| Model | YG-10 | YG-20 | YG-30 | YG-40 |
| Engine | Electric/Diesel | Electric/Diesel | Electric/Diesel | Electric/Diesel |
| Power | 15kw | 22kw | 37kw | 45kw |
| Max. aggregate size | 15mm | 20mm | 30mm | 40mm |
| Conveying Capacity | 6m³/h | 10-15m³/h | 15-30m³/h | 30-40m³/h |
| Horizontal conveying distance | 100-120m | 100-120m | 150-200m | 200-350m |
| Vertical conveying distance | 20-50m | 50-60m | 80-100m | 120-140m |
| Pipe diameter | 80-100mm | 80-100mm | 80-100-125mm | 80-100-125mm |
| Outlet diameter | 80mm | 100mm | 125mm | 125-150mm |
| Material tank diameter | 100mm | 120mm | 140-160mm | 160-180mm |
| Dimension | 1.8×0.7×1.1m | 2.8×1.1×1.3m | 4*1.4*1.5m | 4*1.5*1.5m |
| Weight | 600kg | 900kg | 1800kg | 2500kg |
The small concrete pump price varies based on power, output, and drive type. Electric models are usually more affordable for small projects, while diesel options cost more but offer better mobility. You should always check the aggregate size compatibility with your concrete mix.
How Does the Portable Concrete Pump Work?
The operation is simple. The machine uses a piston-type pumping mechanism to pull concrete from the hopper and push it through the pipeline. It uses a powerful motor to generate high pressure. This pressure allows you to pump the material both vertically and horizontally.
A key component is the hydraulic system. The advanced hydraulic valve group ensures the valve jamming probability is very low. This keeps the machine running smoothly for long hours.
Important operating notes:
- Prepare the mix: Ensure the concrete aggregate size matches the machine specs (e.g., ≤30mm).
- Set up: Place the pump on stable ground near the concrete source.
- Control: Use the one-button start or the wireless remote to manage the flow up to 1000m away.
- Lubrication: The automatic lubrication system ensures all moving parts stay oiled for durability.
3 Advantages of a Portable Pump
Choosing a portable concrete pump for sale offers specific benefits over larger, stationary units. These advantages are important for contractors working on tight sites.
1. Superior Mobility
These pumps are light enough to be moved by a small truck. The compact dimensions allow them to fit through standard doorways and into backyards, making them perfect for urban projects.
2. Efficient Performance
Despite its small size, the pump delivers a steady working efficiency. It can handle up to 40m³/h with a horizontal conveying distance of up to 350 meters. This saves significant manual labor.
3. User-Friendly Design
The smart control panel and remote control operation make it easy to use. You can start the machine with one button. The reinforced hopper design holds more material and resists corrosion, ensuring the machine lasts longer.
Inquire About Product Details
Common Applications on the Job Site
This small concrete pump machine is versatile. It is not just for building skyscrapers. You will find it valuable in various scenarios.
Residential and Commercial Projects
Projects in Peru and Kuala Lumpur demonstrate the pump’s reliability in different conditions.
- Residential: Pouring foundations, columns, and slabs.
- Commercial: Building shopping centers or commercial complexes.
- Farm Construction: Creating feedlots or agricultural buildings.
Infrastructure and Repairs
The pump is ideal for smaller infrastructure tasks.
- Tunnel Construction: Efficiently moving concrete to hard-to-reach areas.
- Road and Bridge Repair: Placing concrete for small patches and repairs.
- Slope and Channel Work: Applying shotcrete or mortar for stabilization.
When looking at the small concrete pump price, consider how versatile the machine is. It can replace a much larger pump for many jobs, saving you money. Contact YG for advice on which model fits your specific application.
Why Choose YG for Your Equipment?
YG is a professional manufacturer with a solid track record. We focus on quality and reliability. Our machines are trusted in demanding markets from South America to Southeast Asia. We offer models with different power options to suit your needs.
Built for Durability
Our pumps feature:
- Reinforced Hopper: Handles tough material and resists wear.
- Integrated Lubrication: Keeps maintenance simple and extends the machine’s life.
- Quality Components: Using high-power motors and wear-resistant parts to reduce downtime.
Performance: Our equipment is built for high performance. For example, our wear-resistant S-valve cutting ring can handle up to 20,000 cubic meters under normal conditions.
YG is dedicated to providing portable concrete pump for sale options that offer value. We are ready to help you with technical support, shipping, and spare parts. Our goal is to make sure you get a machine that pays for itself quickly.
About YG Machinery
YG is a leading factory specializing in construction machinery. We have years of experience manufacturing and exporting portable concrete pumps. Our engineering team focuses on creating reliable, efficient, and easy-to-maintain equipment for global customers. We are committed to using high-quality materials and advanced technology to build durable machines. When you choose YG, you get more than just a product; you get a reliable partner for your construction business.
