In 2025, a farming group in Mendoza, Argentina, faced a serious water shortage. Their land had good soil, but the dry season made it hard to grow crops. They needed a way to reach underground water quickly. They also had to move the drilling machine between many small fields. Large rigs were too heavy and costly to transport.
They searched online for a portable well drilling equipment solution. They found our YG series. After reading the specs, they chose the YG280 model. This small borewell machine runs on 380V power. It drills holes from 80mm to 350mm wide. The depth can go up to 100 meters. That is enough for their irrigation needs.
The client also liked the weight. At 250KG, they could load it onto a pickup truck. They did not need a crane or large trailer. This made the project start much faster.
Match Your Voltage & Depth – Get Model Suggestion
YG Portable Well Drilling Equipment – Customized Support
Our factory makes every small borewell machine with strict quality checks. The YG280 uses a 3kw motor that meets international standards. The gearbox uses hardened steel gears. We test each unit for 2 hours before packing.
Here are the key specs for our popular models (Argentina clients often pick YG280 or YG350):
| Model | YG180 | YG240 | YG280 |
| Voltage | 220V | 220V | 380V |
| Power | 1.5-2kw | 4kw | 3kw |
| Drilling hole | 80-200mm | 80-220mm | 80-350mm |
| Drilling depth | 80M | 100M | 100M |
| Drilling rod | Φ42mm,1.5m | Φ51mm,1.5m | Φ51mm,1.5m |
| Pump power | 2.2kw | 2.2kw | 2.2kw |
| Dimension | 0.7*0.7*2.5m | 0.7*0.7*2.5m | 0.8*0.8*2.7m |
| Weight | 120KG | 150KG | 250KG |
For the Argentina farm, the YG280 was perfect. But if a customer needs deeper wells, the YG350 goes to 120 meters. The YG500 can drill 500mm wide holes for large water projects.
We also pay attention to small details. The pump on the YG280 is 2.2kw. It moves water fast enough to clear cuttings from the hole. The dimension (0.8*0.8*2.7m) means it fits on a standard pallet. The 250KG weight is balanced. The center of gravity is low, so it does not tip over on uneven ground.
Get Small Water Drilliing Rig List
Project Background: Drilling For Crops And Cattle
This Argentina customer has 50 hectares of vines and 200 head of cattle. Before buying, they used a old tractor-powered auger. That tool only went down 15 meters. In the dry months, the water table dropped to 30 meters. Their old machine could not reach it. They had to buy water from trucks, which cost $500 per week.
They needed a reliable portable well drilling equipment that could:
- Drill to at least 80 meters.
- Work with their existing 380V generator.
- Fit into a 20ft shipping container for storage.
- Be operated by two farm workers with basic training.
Our YG280 model matched all these points. The drilling rod is Φ51mm and 1.5m long. This size is strong enough for rocky soil but light enough for manual handling. The pump power is 2.2kw, which gives good water flow for irrigation.
Get Spare Parts List & 2-Year Warranty Details
Application And Feedback from the Argentina Team
The customer started drilling in March 2026. They sent us photos and messages every week. Their first well went down 85 meters. They found water at 70 meters. The second well, 50 meters away, reached water at 55 meters. Both wells produced clean water for the vines and cattle.
The farm manager, Carlos, said: “This small well drilling machine saved our season. We drilled three wells in two weeks. The machine did not overheat. The bits are still sharp. We are very happy.”
His team gave specific positive feedback:
- The 380V motor runs smoothly. It does not trip their generator.
- The 250KG weight makes it easy to move between fields. Two men can push it on flat ground.
- The 80-350mm hole range fits different pipe sizes. They used 4-inch pipes for wells and 6-inch for a large storage tank.
- The 100-meter depth gives them a safety margin. Even if the water table drops, they still have water.
They also praised the simple control panel. They did not need an engineer to run it. The manual had clear pictures. We sent a video in Spanish, which helped a lot.
Why Argentina Customer Chose YG’s Portable Well Drilling Equipment
There are many drilling machine sellers online. But this client chose us for five clear reasons.
First, they needed a portable well drilling equipment that fits a 20ft container. Our YG280 dimensions are 0.8*0.8*2.7m. That is small enough. They could also store it inside their barn, safe from rain.
Second, they compared voltage options. Our YG350 runs on gasoline/diesel, but they already had a 380V generator. So the YG280 was the most cost-effective choice. They saved fuel costs.
Third, they asked about spare parts. We gave them a list of common wear parts (seals, bits, belts). We shipped these with the machine. They did not have to wait for local suppliers.
Fourth, we offered a 2-year warranty on the motor and gearbox. This gave them confidence. Many competitors only gave 6 months.
Fifth, we provided free drilling tips for Argentine soil. We knew that Mendoza has sandy loam with some gravel. We recommended a specific bit type. That bit worked perfectly. They did not waste time with trial and error.
Check Shipping Cost To Argentina
Why YG Machinery Service Makes A Difference
We do not just sell machines. We help customers succeed. For this Argentina client, we did three extra things:
- We translated the manual into Spanish.
- We marked all grease points with bright stickers.
- We gave a WhatsApp number for instant support.
When Carlos had a question about bit rotation speed, we replied in 10 minutes. We also sent a short video showing how to change the drill rod. This level of care is rare in the drilling industry.
Our shipping team packed the YG280 in a wooden crate. They used anti-rust oil on all metal parts. The machine arrived in Buenos Aires in 35 days. Customs cleared it quickly because we provided all required documents.
Tell Us Your Farm Size – We Recommend The Right Rig
The Result: Water Security And Happy Customers
Today, the Argentina farm has four working wells. They use the portable well drilling equipment twice a month for maintenance drilling. They also lend it to three neighboring farms. This builds good community relations.
Carlos told us: “This small well drilling machine paid for itself in one season. We saved $20,000 in water truck costs. We also increased grape yield by 30% because we irrigated on time.”
He also said they plan to buy a YG350 next year for deeper exploration. They trust our quality and service.
Final Thoughts For Buyers In Argentina And South America
If you need a portable well drilling equipment for farms, villages, or construction sites, consider these points:
- Match the voltage to your local supply (220V or 380V are common).
- Choose a depth rating that is 20% more than your current water table.
- Check the weight – can your truck or trailer carry it?
- Ask for spare parts at the time of purchase.
Our YG series offers solutions from 80 meters to 120 meters. The hole sizes range from 80mm to 500mm. Whether you need a small borewell machine for a garden or a larger rig for a community project, we have a model for you.
We ship worldwide, including Argentina, Chile, Brazil, and Uruguay. Every machine comes with a test video and a packing list. We stand behind our products. Contact us for a quote. We will help you choose the right small well drilling machine for your land and budget.
