A self-loading concrete mixer truck combines three machines into one. It loads raw materials, mixes concrete, and transports it to where you need it. This machine replaces a loader, a mixer, and a transport truck.
The self loading mixer truck works on its own. You do not need extra workers to load materials. One operator can handle the whole process. The machine drives to the site, scoops sand and gravel, adds cement and water, and mixes everything. Then it pours the concrete exactly where you need it.
This is different from a regular concrete mixer truck. Regular trucks need a loader to fill them. They also need a separate batching plant to mix the concrete. The self loading concrete mixer truck does everything by itself.
Key components include:
- Hydraulic loading bucket (0.4-0.8m³ capacity)
- Mixing drum (rotates 270° for flexible discharge)
- 4×4 off-road drive system
- Automatic water supply with timer control
- Weighing system for accurate batching
Self-Loading Concrete Mixer Truck Specification-Customized Support
Below are typical parameters for different output sizes:
| Model | YG1.8 | YG2.6 C | YG3.5 C | YG4.0 C |
| Output per Lot | 1.6 m³ | 2.6 m³ | 3.5 m³ | 4.0 m³ |
| Production Capacity | 8 m³/h | 11 m³/h | 15.5 m³/h | 18 m³/h |
| Engine Power | 78 KW | 78 KW | 85 KW | 91 KW |
| Climbing Capacity | 30° | 30° | 40° | 40° |
| Weight | 6300KG | 7000KG | 8250KG | 9000KG |
| Length/width/height | 6700*2340*2700mm | 6650*2700*3200mm | 7300*2750*3350mm | 7700*2950*3400mm |
| Wheelbase | 2500mm | 2770mm | 2750mm | 2950mm |
The drum rotates 270° on the horizontal level. This means you can pour concrete in many directions without moving the truck. The discharge chute is removable and can rotate 90° for precise placement.
Get a Quote for Your Project Size
5 Main Applications of the Self Loading Mixer Truck
The self loading mixer truck works in many places where regular concrete trucks cannot go:
1. Rural Construction
Villages have narrow roads. Large trucks cannot enter. The compact self-loading concrete mixer truck fits through tight spaces. It is ideal for houses, farm roads, and irrigation.
2. Remote Job Sites
Some sites have no power supply. The self mixing concrete truck runs on diesel. It does not need electricity. Perfect for mountains, mines, and desert projects.
3. Tunnel and Bridge Projects
The truck’s 4×4 drive handles rough underground conditions. Its small turning radius works well in confined areas.
4. Urban Small Projects
For city repairs, sidewalks, and small buildings, one truck does the whole job. No large batching plant needed.
5. Infrastructure Development
Highway and port projects use these trucks for fast concrete supply. Output reaches 12-14m³ per hour.
Self-Loading Mixer Truck vs. Traditional Concrete Trucks
Many contractors ask: Why buy a self-loading concrete mixer truck instead of a standard mixer? Here is the comparison:
| Factor | Standard Mixer Truck | Self-Loading Mixer Truck |
| Workers Needed | 3-4 | 1 operator |
| Loading Method | Needs separate loader | Loads itself |
| Batching Location | Fixed plant | On-site, anywhere |
| Concrete Waste | Higher | Lower |
| Site Access | Requires wide roads | Fits narrow roads |
| Setup Time | 30-60 minutes | Under 10 minutes |
Key advantages:
- Saves Labor: One operator cuts labor costs by up to 70%
- Saves Time: No waiting for loader or batching plant
- Saves Material: Mix only what you need, no waste
- More Flexible: Move between sites easily, drives at 35km/h
How to Choose the Best Self-Loading Concrete Mixer Truck
Use this guide to make the best decision:
1. Calculate Your Daily Concrete Needs
For small jobs (under 10m³/day), choose 1.8m³ or 2.6m³ models. For bigger projects, choose 3.5m³ to 5.5m³ models.
2. Check Your Site Conditions
- Flat, hard ground: Standard tires work fine
- Mud, gravel, slopes: Choose 4×4 drive
- Tight spaces: Smaller models with short turning radius
3. Consider the Rock Type
- Soft rock, soil: Standard buckets work
- Hard rock, large stones: Ask for reinforced bucket
4. Look for Useful Features
- Weighing system: Measures materials accurately for consistent quality
- 270° rotation: Pour in multiple directions without moving
- Camera system: Helps driver see loading and pouring area
5. Consider Customization
Options include engine brands (Yuchai, Cummins), color, and cab with air conditioning.
Features That Make the Self Loading Concrete Mixer Truck Reliable
The self loading concrete mixer truck offers several practical features:
- Integrated Design: One-piece frame makes the truck stable and durable
- Simple Operation: One joystick controls loading. Workers learn in hours
- Articulated Chassis: Bends in the middle for better turning
- Hydraulic Transmission: 4×4 drive provides smooth power, climbs up to 40°
- Safety Brakes: Wet brakes on front, air brakes on rear
- Easy Maintenance: High-pressure wash system cleans drum quickly
Why Choose YG’s Self-Loading Concrete Mixer Truck?
We sell directly to customers. No middlemen mean better prices and faster service.
What we offer:
1. 4×4 Drive Standard
Every YG self loading mixer truck comes with four-wheel drive. Off-road capability on every model.
2. 270° Rotation Standard
Pour concrete in almost any direction without moving the truck. Saves time on busy sites.
3. Weighing System Included
Electronic weighing measures sand, gravel, and cement accurately. Consistent quality batch after batch.
4. One-Year Warranty
Cover all core components for one year. Fast technical support.
5. Fast Delivery
In-stock models ship within 7 days. Custom orders take about 20 days.
